Design Radiology
Integrations.
Ship with Confidence.
Visually model DICOM, HL7, and FHIR workflows between PACS, RIS, modalities, and EMR systems. Simulate interactions, generate artifacts, and present ROI reports — no code required.
MSH|^~\&|EPIC_EHR|EPIC|SECTRA_RIS|SECTRA|20260402143000||ORM^O01|MSG-001|P|2.5 PID|1||MRN-12345^^^EPIC^MR||DOE^JOHN^A||19800101|M ORC|NW|ORD-20260402001|||SC||||20260402143000 OBR|1|ORD-001||71250^CT CHEST W/CONTRAST^CPT|||20260402143000
MSH|^~\&|SECTRA_RIS|SECTRA|EPIC_EHR|EPIC|20260402143001||ACK^O01|ACK-001|P|2.5 MSA|AA|MSG-001|Order accepted successfully Order Status: SC (Scheduled) Scheduled Time: 20260402 14:30 Modality: CT Procedure: CT CHEST W/CONTRAST
Artifact generation
From diagram to
deployment artifacts.
Stop manually configuring channels. Once your workflow is designed, Radinode generates production-ready integration artifacts — so your team moves from design to deployment in minutes, not days.
- Mirth Connect channel XML — ready to import
- BridgeLink channel configs & API definitions
- HL7 v2 sample messages per connection type
- FHIR R4 resource bundles
- Canonical JSON for custom tooling
Select the artifact formats to generate from your workflow diagram.
Integration planning
From kickoff charter
to living project tracker.
Your integration plan doesn't end at kickoff. Radinode keeps it alive for the duration of the project — task statuses, phase progress bars, a blocker log, and an activity feed that shows every update in real time.
- 7 standard healthcare phases — pre-populated, drag to reorder
- Live task status tracking — flip tasks to In Progress, Blocked, or Complete with one click
- Blocker & issue log — track issues with severity and owner, linked to specific phases
- Export a PDF charter for kickoff, or share a live client status link — always up to date
Client visibility
Stop emailing PDFs.
Share a live status link.
Clients ask “where are we?” and consultants email a PDF that's outdated the moment it's sent. Radinode generates a unique, bookmarkable status link your client can check any time — always showing the latest plan progress with no login required.
- One click generates a unique shareable link — no login required for your client
- Clients see real-time phase progress bars, task statuses, and health indicators
- Toggle whether issues and the activity feed are visible to your client
- Revoke the link at any time — no more chasing down outdated emailed PDFs
Proposal generator
Write your next SOW
in minutes, not hours.
Your workflow already has every system and interface. Radinode turns that into a professional Scope of Work — with auto-calculated pricing, phase timelines, and a branded PDF — ready to send to a client the same day you design the integration.
- Auto-populate systems and interfaces directly from your workflow diagram
- Import phases from your integration plan or start from a 7-phase template
- Enter your hourly rate and complexity estimates — totals calculate automatically
- Export a branded PDF with cover page, scope table, pricing, and sign-off
Everything you need
Built for radiology IT professionals
From first diagram to signed-off integration — Radinode covers every step of the design, simulation, and documentation workflow.
Visual Workflow Builder
Drag PACS, RIS, Modality, EMR, and integration engines onto a canvas and connect them in minutes — no Visio or draw.io required.
Healthcare Protocols
Model real integrations with DICOM (MWL, C-STORE, C-FIND), HL7 v2 (ORM, ADT, ORU, SIU), and FHIR R4 — all built-in.
Interactive Simulation
Click any connection to see a simulated request/response — from a Modality Worklist query to a C-STORE image transfer.
Reusable Templates
Start from pre-built radiology workflows or save your own diagrams as templates for proposals, demos, and training.
Artifact Export
Generate Mirth Connect channels, BridgeLink configs, HL7 message templates, and FHIR R4 resources directly from your diagram.
ROI Calculator
Build polished before/after ROI reports with time savings, error reduction metrics, and executive summaries — PDF-ready.
Client Management
Organize workflows, templates, and ROI reports per client. Keep every integration design linked to the right account.
Custom Protocols
Create protocols with custom names, categories, colors, and sample payloads — beyond the built-in DICOM/HL7/FHIR set.
Integration Plans
Generate a professional PDF project charter from your workflow — phases, Gantt timeline, partner assignments, and a sign-off page, ready for kickoff.
Live Execution Tracker
Track task progress in real time — flip statuses, log blockers, view an activity feed, and monitor overall plan health from one screen.
Client-Shareable Portal
Generate a live, public status link for your client. They see real-time phase progress and health indicators — no login, no outdated PDFs.
SOW & Proposal Generator
Turn your workflow into a signed-off Scope of Work in minutes — auto-populated scope, effort estimates, pricing calculator, and PDF export.
Who it's for
Built for every role in the room
Whether you're selling, building, or documenting — Radinode fits your workflow, not the other way around.
Sales Engineers
Close deals with live, interactive demos
- Build integration proposals in minutes, not days
- Show real DICOM and HL7 workflows for your product
- Impress clients with simulated payload exchanges
Radiology IT Professionals
Design and validate before you build
- Map multi-system architectures visually
- Catch integration errors before they reach production
- Document AE titles, IP addresses, and ports per system
Solutions Architects
From diagram to deployment in one click
- Export Mirth Connect channels from any workflow
- Generate HL7 and FHIR artifacts automatically
- Reuse templates across similar integrations
Training & Education Teams
Make complex protocols understandable
- Visual diagrams anyone can follow and present
- Live payload simulations for hands-on learning
- Onboard new staff on DICOM, HL7, and FHIR
Simple workflow
From blank canvas to complete integration
Four steps is all it takes to go from nothing to a fully documented, simulated, and deployment-ready integration architecture.
Add your systems
Drag PACS, RIS, Modality, EMR, and middleware nodes onto the canvas. Configure each with AE Titles, IP addresses, and ports.
Connect with protocols
Wire systems using DICOM, HL7, or FHIR connections. Choose from 9+ built-in protocols or create your own custom ones.
Simulate interactions
Click any connection to preview live payloads — HL7 ORM messages, DICOM C-STORE transactions, and FHIR REST calls.
Export & deploy
Generate Mirth Connect channels, BridgeLink configs, HL7 templates, and FHIR resources — or export a full PDF integration plan and ROI report for stakeholders.
Standards support
The three pillars of radiology interoperability
Radinode ships with first-class support for every major healthcare integration standard used in radiology today.
Medical Imaging Standard
The universal language for storing, transmitting, and managing medical images across all imaging modalities and PACS systems.
- Modality Worklist (MWL)
- C-STORE
- C-FIND
- C-MOVE
- C-ECHO
Healthcare Messaging
Event-driven messaging for clinical workflows — from patient admission through order placement to results delivery.
- ORM — Orders
- ADT — Admissions
- ORU — Results
- SIU — Scheduling
Modern Healthcare API
RESTful API standard powering the next generation of interoperability, patient data access, and healthcare application integration.
- FHIR REST
- ImagingStudy & ServiceRequest
- Patient & Observation
- JSON / XML
Ready to simplify your integrations?
Join radiology IT teams who use Radinode to design, simulate, and deploy integration architectures — without writing a single line of code.
No credit card required · Free plan available
